The world needs to capture, use, and store gigatons of CO2: Where and how?

| Article

Countries and companies around the globe are committing to net zero by 2050. One suite of technologies—collectively called carbon capture, utilization, and storage (CCUS)—offers solutions for many hard-to-abate sectors such as aviation, cement, and hydrogen production from fossil fuels. However, global CCUS uptake needs to expand 120 times from current levels by 2050, rising to at least 4.2 gigatons per annum (GTPA) of CO2 captured, for countries to achieve their net-zero commitments.1Scaling the CCUS industry to achieve net-zero emissions,” McKinsey, October 28, 2022.

There are two routes for captured CO2: permanent storage (CCS) or utilization by converting into products (CCU). The potential for CCUS is highly dependent on factors including the emissions source, industry, capture technology, transportation, as well as location and type of storage. Thousands of CO2 point source facilities exist that could be suited to carbon capture and storage (CCS), with varying concentrations of CO2 in the flue gas and differing proximity to storage sites, which can affect the viability for CCS for these facilities. Future emission sources may exist near facilities that use captured CO2 to create products such as fuels, chemicals, and building materials, and near oil and gas wells where they can be used for enhanced oil and gas recovery (EOR/EGR). Utilization has the added benefit over CCS of generating revenue to offset the cost of capture and transport.

However, many, if not most, CCUS projects are economically challenged today, with high costs of capture for dilute point sources and a limited number of revenue streams available.2Scaling the CCUS industry to achieve net-zero emissions,” McKinsey, October 28, 2022. For CCUS to reach levels needed to achieve net-zero commitments, lowering costs may be vital. Developing cross-industry hubs that share CCUS infrastructure and resources across multiple companies could reduce the risks associated with the upfront investment capital that individual emitters may be unable to burden alone.

This article explores potential CCUS hubs, five emerging hub archetypes, and three key steps to accelerate the development of CCUS hubs.

Creating CCUS hubs can accelerate development

A CCUS hub is a cluster of emission facilities that share the same CO2 transportation and storage or utilization infrastructure. There have been several recent government funding calls for hub developments in Canada, Europe, and the United States to address industrial emissions and accelerate the development of both carbon-removal technology and infrastructure.3 There are approximately 15 CCUS hubs globally under various stages of development, with many more being planned.4

In the United States, CCUS has recently been boosted by the Inflation Reduction Act, which offers an increased tax credit for captured point source CO2 from $50 to $85 per ton.5 Many industrial use cases such as ammonia production, ethanol plants, and natural gas processing facilities are now economically “in the money” in the United States with the increased 45Q tax subsidy.6 This subsidy provides $85 per ton for sequestered industrial or power emissions, and $180 per ton for emissions captured directly from the atmosphere and sequestered.

Shared transportation, utilization, or storage infrastructure could lower costs, increase savings through economies-of-scale, provide additional options for managing or sharing risks, and strengthen regional visibility for support by governmental entities. Hubs may, however, bring companies together from different sectors that do not normally work together, which can introduce project complexity as there are multiple collaborators across different industries, all with different timelines and objectives.

Would you like to learn more about our Oil & Gas Practice?

We developed a macro-model to assess the viability of future CCUS hubs (see sidebar, “Our methodology”). This model considers a range of factors, including point source industries and purity of the emissions streams (which determines their potential for utilization or storage, or both), the physical proximity of the emitters to potential storage sites, and the potential for shared infrastructure costs, operating costs, and other commercial synergies within a cluster.

Our analysis suggests that approximately 700 CCUS hubs could be established globally. Most of these hubs are located on, or close to, potential storage locations and EOR/EGR sites, with more than 60 percent located within 50 miles from potential storage sites (Exhibit 1). East Asia could become a hub hotspot since the region’s high emission volume could be covered by its high storage capacity (Exhibit 2).

For each potential hub consisting of five nearby emitters or more, we have calculated a total carbon-abatement cost, which includes the cost of capture, compression, transportation, and storage. Additional variable costs such as financing, vendor margins, and contingency are project specific and not included here, but need to be factored in to understand real-world cost of abatement.

Capture costs are typically the largest cost in the CCUS value chain and vary considerably between technologies and industries.7 One of the key factors here is the concentration of CO2 in the emissions stream. High concentration streams, such as those from ethanol and ammonia processes, where CO2 is 50 to 90 percent of the emissions, are the cheapest to capture.8 However, such sources represent less than 5 percent of the worldwide emissions volume. Low-concentration sources, such as power generation, cement, and petrochemical production, with CO2 concentrations in emissions streams of between 5 and 15 percent, represent the greatest share of emissions and are also the costliest to capture.9

As compression is a mature and well-established process, this cost element is typically well-understood and less variable between operations. Transportation cost is highly dependent on proximity to storage sites, transport mode, terrain, and whether sites are located on land or offshore. Finally, storage cost is dependent on the type of storage used (onshore, offshore, reservoir, geologic, etcetera).

The resulting emission-abatement cost curve shows that if 440 hubs are developed, 9 GTPA to 10 GTPA of existing emissions could be abated at a cost of less than $100 per ton CO2 (Exhibit 3). Furthermore, the world could reach its 4.2 GTPA net-zero goal by 2050 through the development of approximately 160 CCUS hubs at costs of less than $85 per ton CO2.

3
With the development of 440 hubs, 9-10 GTPA of existing emissions could be abated at a cost of less than $100 per ton of CO2.

While the total addressable CO2 abatement from CCUS is based on clusters of emission point sources, we should note that much of the decarbonization may come from other levers (for example, increased energy efficiency, fuel switching, or electrification) prior to CCUS being adopted. Some of the high-emitting facilities included in the model may be nearing their end of life and will simply be decommissioned, or there is a potential for disruptive new technologies to decarbonize their supply chain, such as electric arc furnaces for steel production. In many situations and use cases, CCUS serves as a backstop for emissions that are difficult or impossible to decarbonize using other means.

Five emerging hub archetypes

Five hub archetypes sharing common features across regions and sectors emerge when the industrial make-up of an emissions cluster drives the formation of these hubs. These archetypes each have unique characteristics that will likely shape their business case, operating model, governance, and potential impact:

  1. Large emitter-dominated hubs are characterized by the presence of multiple emission point sources greater than 1 million tons per annum (MTPA). Sometimes these facilities may be so large that they require their own dedicated CCUS infrastructure and can afford the capital expenditures to deploy CCUS. They may still be open to partnering with other smaller emitters to create a hub. These facilities are primarily power plants, but may also be large iron, steel, or cement facilities. Point sources are typically lower purity with higher costs, making them better suited to storage than utilization, but lower project complexity due to the reduced number of players may lead to faster execution. Smaller emitters that would not be able to afford the build-out of CCUS infrastructure may benefit from proximity to a large emitter as a bolt-on. While there are large CCUS facilities in operation today, there have yet to be hubs that have formed around existing infrastructure.
  2. Cross-industry hubs are built around industrial parks with a mixture of high and low-emission facilities with varying costs across different sectors and industries (for example, a cement facility located near an ammonia production plant and a refinery). These industry-balanced hubs are typically centered around common CCUS infrastructure, such as a transport pipeline that collects CO2 from various sources. A combination of utilization and storage may work at such hubs, with different purity streams used for different purposes. Cross-sectoral collaboration between industries not accustomed to working together may lead to higher project complexity. An example of a cross-industry hub is the Alberta Carbon Trunk Line (ACTL), which captures CO2 emissions from an oil refinery and fertilizer facility that shares a pipeline to storage for EOR. The ACTL was designed with a larger capacity to accommodate future emitters.
  3. Storage-led hubs are strategically located near ports for shipping or near geological storage to reduce the need for onshore and offshore pipeline transportation. Creating hubs that are located close to storage can reduce costly transportation infrastructure. In locations where onshore geological storage may be limited due to regulation or public acceptance, such as in Europe, offshore storage-led hubs are more likely to emerge. An example of a storage-led hub is the Porthos CCUS project, which captures CO2 emissions from facilities in the Port of Rotterdam and then stores them in gas fields under the North Sea.
  4. Smaller, higher-purity emitter hubs consist of a higher number of facilities with relatively high-purity CO2 streams (such as ethanol production plants) and therefore typically lower capture costs. However, aggregation across multiple facilities is required to achieve economies of scale and share the capital burden to build transport, storage, and utilization infrastructure. Such hubs may be better suited to utilization than storage, to take advantage of high-quality streams of CO2. Due to the larger number of smaller facilities, there is likely to be increased project complexity, which may slow progress or complicate operations. An example of a smaller, higher-purity emitter hub is the CCUS pipeline network in the Midwest that will capture emissions from ethanol biorefineries and is being developed by companies like Summit Carbon Solutions, Navigator, Wolf Carbon Solutions, and ADM.
  5. Carbon-removal-led hubs are built around direct air capture (DAC) or bioenergy carbon capture and storage facilities. Since a DAC facility could theoretically be deployed directly around carbon removal-driven hubs, and could also overlap with a storage-driven hub, the infrastructure built for carbon-removal technology (such as pipelines, CO2 compression, and monitoring and measurement subsurface technologies) could be shared by other nearby emitters. The CO2 captured from the atmosphere by these hubs is also well suited for utilization to produce synfuels such as sustainable aviation fuels. The US Department of Energy’s Office of Clean Energy Demonstration announced $2.5 billion for the development of regional DAC hubs, with applications due in March 2023.10 An example of carbon-removal-led hubs is the recent announcement from Occidental Petroleum and King Ranch to remove and store up to 30 MTPA of CO2 using DAC.11

Large emitter-dominated hubs may have improved deployment speed due to organizational simplicity with one dominant stakeholder. However, cross-industry or storage-led hubs may be more resilient as the success of the hub is diversified across multiple organizations and the fate of the entire hub is not dependent on one facility. Hubs that have some form of utilization may also emerge faster than those focused on storage alone, as utilization provides a stream of revenue to offset the costs.

Ultimately, proximity to storage, availability of renewable energy for powering carbon removals, opportunities for utilization, and willingness of parties to cooperate will likely drive the business cases for the formation of many of these hubs. Integration with other emerging climate technologies, such as hydrogen production and sustainable aviation fuels, may also drive adoption.

" "

Scaling the CCUS industry to achieve net-zero emissions

How can we accelerate the development of CCUS hubs?

Our recent research shows that an annual global investment in CCUS technology of $120 billion to $150 billion by 2035 is required to achieve net zero.12Scaling the CCUS industry to achieve net-zero emissions,” McKinsey, October 28, 2022; Global Energy Perspective 2022, McKinsey, April 26, 2022; McKinsey Energy Insights. To scale CCUS effectively, greater coordination across the value chain may be needed. The following three key actions could speed up CCUS-hub development worldwide:

  1. Identify no-regrets activation projects within regions that are feasible under existing economic conditions and around which hubs can begin to form. Building hubs around high-purity sources with lower CO2 capture costs may allow for quicker learning that can be applied to larger-scale sources of CO2 emissions that are more expensive to capture. These initial hubs can be designed to accommodate modularity and flexibility for expansion to take advantage of potential future economies of scale or cost compression from technological advances.
  2. Build market mechanisms to ensure value and risk are apportioned appropriately across the hub. It is important to understand the value and risk across capture, transportation, storage, and utilization in different regions and situations. Sharing learnings and best practices from the development of hubs can facilitate risk sharing, improve safety, standardize storage monitoring, and ensure governance and business models follow best practices. Creating standards around the capture, utilization, monitoring, and measurement of CO2, and end-of-life liability management, could give investors confidence in capitalizing on CCUS hubs.
  3. Design hub networks to be resilient and adaptable to change. Developing a CCUS hub is a multistep process that can require significant collaboration between industry players that are often not accustomed to working together. The network between capture and storage may need to be carefully designed. For example, a hub may choose a trunk line model that aggregates many emissions into one pipeline with one storage location, or it may choose a network approach with multiple sequestration and transportation options and flexibility across sinks and sources.

Carbon capture, utilization, and storage offers a way to reduce the emissions of our existing infrastructure, especially for hard-to-abate sectors, while we continue to improve renewables and electrification. By working together, pooling resources, and sharing critical infrastructure, CCUS hubs could lower the costs associated with capturing, transporting, utilizing, and storing CO2. Considerable volumes of CO2 remain to be captured, and we can accomplish significantly more by working together than laboring alone.

Note: This article was updated to correct a mapping error.
